SN:B007
Size:M1.2*20T*10L
The Super Screw is a high-performance POM gear (also known as “Acetal” or “Delrin”)—a durable, metal-like engineering plastic designed for precise, low-noise power transmission in light-duty mechanical systems. Ideal for use in applications where quiet operation, durability, and long service life are crucial.
Product Specifications
| Parameter | Specification |
| Module (M) | 2.5 |
| Number of Teeth (Z) | 17 |
| Outer Diameter | Φ26.5 mm |
| Shaft Hole Diameter | Φ14 mm |
| Gear Thickness | 10 mm |
| Material | POM (Polyoxymethylene) |
Metal-like Performance:
Made from POM (Polyoxymethylene), also called “plastic steel”, this gear combines high strength, rigidity, and excellent impact resistance, providing near-metal performance while being lightweight.
Superior Wear Resistance:
The self-lubricating surface of POM significantly reduces friction, extending the gear’s service life by up to 3 times compared to traditional plastic gears.
Stable Dimensions & Durability:
With low water absorption and excellent dimensional stability in temperatures ranging from -40℃ to 100℃, POM ensures that the gear maintains consistent, precise transmission performance.
Low Noise Operation:
The smooth tooth surface and POM’s natural damping properties reduce operational noise to ≤40dB, offering a quieter solution compared to metal gears—ideal for noise-sensitive environments.
Cost-Effective & Lightweight:
POM gears are budget-friendly and reduce the overall weight of mechanical systems, making them an excellent choice for light-duty, cost-conscious applications.
The Super Screw POM gear is designed for use in light-duty mechanical systems, ideal for environments where precision, durability, and quiet operation are key factors. Some of the primary applications include:
Office Equipment: Printers, copiers, and scanners.
Home Appliances: Blenders, small fans, coffee machines, etc.
Automation Components: Light-duty conveyors, small robots, automated systems.
Toy Models & DIY Projects: Perfect for precision models and DIY mechanical applications.
Material:
POM (Polyoxymethylene), a high-performance thermoplastic, offers metal-like performance with high rigidity, excellent wear resistance, and durability.
Wear Resistance:
Thanks to its self-lubricating properties, POM provides a low friction coefficient, ensuring a long service life and reducing the need for maintenance in high-usage applications.
Low Noise:
The Super Screw operates at a noise level of ≤40dB, which is significantly quieter than metal gears. Its damping properties make it ideal for office environments, home appliances, and any system where noise is a concern.
